一个vue组件的集成

vue集成步骤:

1. package.json 添加vue的依赖

2. 继承对应的基类

yh-designer包已经定义的系统vue组件的基类:

• VueCmpBase vue组件基类
• VueDbCmpBase vue组件数据库组件基类. 功能: 属性包含了绑定数据源
• VueFieldDbCmpBase vue组件绑定数据源字段的组件基类. 功能: 属性包含了绑定数据源和字段的绑定
• VueInputBase vue组件输入组件基类 功能:属性包含value以及函数setValue,getValue 的输入类型的组件

  3.添加组件代码如:

ElStep.ts

import { Step, Steps } from 'element-ui';
import * as _ from "lodash";
import Vue from 'vue';
import { IContainerBase } from "yh-designer/dist/base/ComponentBase";
import { Component, serialize, VueacType, vueEditor } from "yh-designer/dist/base/decorators/Decorators";
import { Common } from "yh-designer/dist/utils/Common";
import { ElStepItemsAttrEditor } from '../attrbuteEditors/ElStepItemsAttrEditor';
import { VueCmpBase } from "../base/VueCmpBase";




Vue.use(Steps)
Vue.use(Step)

/**
 * 步骤
 */
export interface IStepItem {
    /**
     * 标题
     */
    title: string;
    /**
     * 描述
     */
    description?: string;
    /**
     * 图标
     * 参考: https://element.eleme.cn/#/zh-CN/component/icon
     */
    icon?: string;
    /**
     * 状态
     */
    status?: ElStepProcessStatus
}

/**
 * 方向
 */
export enum ElStepDirection {
    horizontal = 'horizontal',
    vertical = 'vertical',
}
/**
 * 设置当前步骤的状态
 */
export enum ElStepProcessStatus {
    wait = 'wait',
    process = 'process',
    finish = 'finish',
    error = 'error',
    success = 'success',
}

/**
 * 设置分割线文案的位置
 */
export enum ElStepContentPosition {
    center = 'center',
    left = 'left',
    right = 'right',
}




type ElStepStyle = {
    ElStep
}
/**
 *Steps 步骤条
 * 参考 https://element.eleme.cn/#/zh-CN/component/steps
 */
export class ElStep extends VueCmpBase {
    /**
    * 每个 step 的间距，不填写将自适应间距。支持百分比
    */
    @vueEditor(String, { labelCaption: '每个 step 的间距', placeholder: '20% , 100px', vue: {} })
    space: string

    /**
     * 所有的步骤
     */
    @vueEditor(Array, { labelCaption: '编辑选项', editorClass: Common.getClassName(ElStepItemsAttrEditor) })
    steps: IStepItem[]


    /**
    * 设置分割线方向
    */
    @vueEditor(ElStepDirection, { labelCaption: '设置当前激活步骤', placeholder: '20% , 100px', vue: {} }, ElStepDirection.horizontal)
    direction: ElStepDirection

    /**
     * 设置当前激活步骤
     */
    @vueEditor(Number, { labelCaption: '设置当前激活步骤', placeholder: '20% , 100px', vue: { attr: ':active' } }, 0)
    activeStepIndex: number

    /**
     * 设置当前步骤的状态
     */
    @vueEditor(ElStepProcessStatus, { labelCaption: '设置当前步骤的状态', vue: { attr: 'process-status' } }, ElStepProcessStatus.process)
    processStatus: ElStepProcessStatus;


    @vueEditor(ElStepProcessStatus, { labelCaption: '是否进行居中对齐', vue: { attr: 'finish-status' } }, ElStepProcessStatus.process)
    finishStatus: ElStepProcessStatus;

    /**
     * 是否进行居中对齐
     */
    @vueEditor(Boolean, { labelCaption: '是否进行居中对齐', vue: { attr: 'align-center', type: VueacType.AttrNoVal } })
    isAlignCenter: boolean

    /**
     * 是否应用简洁风格
     */
    @vueEditor(Boolean, { labelCaption: '是否应用简洁风格', vue: { type: VueacType.AttrNoVal } })
    simple: boolean


    constructor(config: IContainerBase) {
        super(config);
        this.isDropCreate && this.buildDefalut();
        this.canChildComponentsDragPut = false;
        this.canChildComponentsDragPull = false;
    }

    buildDefalut() {
        let items = this.steps;
        if (items.length == 0) {
            for (let i = 0; i < 4; i++) {
                let newStep = { title: '步骤' + (i + 1) };
                this.steps.push(newStep)
            }
        }
    }

    css: ElStepStyle
    doGetCss(): ElStepStyle {
        const styles = {
            ElStep: {

            }
        }
        return styles;
    }
    doGetClassName() {
        return this.css.ElStep;
    }
    /**
     *  **注意**:使用注解注册属性编辑器这里不能少
     */
    getAttrEditors() {
        let attrs = super.getAttrEditors()
        return attrs.concat(this.getAttrsByClassName(ElStep));
    }
    /**
    * 获取组件的html
    */
    getElemtHtml() {

        let cmpAttr = this.getVueAttrStr(),
            onClickEvent = ''
        return [
            , '<el-steps ' + cmpAttr + ' ' + onClickEvent + this.doGetCmpIdTypeStr() + '>' + this.getItemsHtml() + '</el-steps>'
        ].join('')
    }
    getItemsHtml() {
        let ret = [];
        for (let i = 0; i < this.steps.length; i++) {
            const step = this.steps[i];
            let attrTitle = this.getAttrStr(step.title, 'title'),
                Description = this.getAttrStr(step.description, 'description'),
                AttrIcon = this.getAttrStr(step.icon, 'icon');
            let cmpAttr = AttrIcon + attrTitle
            ret.push('<el-step ' + cmpAttr + Description + '></el-step>')
        }
        return ret.join('')
    }

    protected doDesigningDbClick() {
        this.linkEditorOnDesigningDbClick('steps');
    }
    /**
     * 设置默认值
     */
    doGetVueData() {
        let vueData = super.doGetVueData()
        return vueData
    }
    /**
     * 事件
     */
    doGetMethods() {
        let ret = super.doGetMethods();
        let that = this;
        return _.merge(ret, {
            next() {
                that.nextStep();
            }
        })
    }

    /**
     * 下一步
     */
    public nextStep() {
        if (this.activeStepIndex++ > this.steps.length - 1) this.activeStepIndex = this.steps.length;
        this.doUpdate();
    }

    /**
     * 上一步
     */
    public preStep() {
        if (this.activeStepIndex-- > 0) this.activeStepIndex = 0;
        this.doUpdate();
    }

    /**
     * 返回是否已经完成了最后的步骤
     * @return true 已经最后步骤
     */
    public isLast() {
        return this.steps.length == 0 || this.activeStepIndex == this.steps.length;
    }

    /**
     * 获取步骤
     * @param index 步骤顺序索引
     * @return 返回步骤对象
     */
    public getSetp(index: number) {
        return this.steps[index];
    }
    /**
     * 设置步骤的状态
     * @param index 步骤的位置索引
     * @param status 状态
     */
    public setSetpStatus(index: number, status: ElStepProcessStatus) {
        if (index < this.steps.length) {
            this.steps[index].status = status;
        }
    }

    /**
     * 设置当前步骤的状态
     * @param status 状态
     * @param foreUpdate 可选参数 是否强制刷新组件 默认true
     */
    public setCurrStepStatus(status: ElStepProcessStatus, foreUpdate: boolean = true) {
        this.setSetpStatus(this.activeStepIndex, status);
        foreUpdate && this.doUpdate();
    }

    /**
     * 新增步骤
     * @param step 步骤
     * @param foreUpdate 可选参数 是否强制刷新组件 默认true
     * @returns 返回step
     */
    public addStep(step: IStepItem, foreUpdate: boolean = true) {
        this.steps.push(step);
        foreUpdate && this.doUpdate();
        return step;
    }

    /**
     * 移除步骤
     * @param step 步骤
     * @param foreUpdate 可选参数 是否强制刷新组件 默认true
     */
    public removeStep(step: IStepItem, foreUpdate: boolean = true) {
        _.remove(this.steps, (item) => { return item.title == step.title });
        foreUpdate && this.doUpdate();
    }

    /**
     *  更新步骤
     * @param step 步骤
     * @param foreUpdate 可选参数 是否强制刷新组件 默认true
     * */
    public updateStep(step: IStepItem, foreUpdate: boolean = true) {
        let it = _.find(this.steps, (item) => { return item.title == step.title })
        _.assign(it, step);
        foreUpdate && this.doUpdate();
    }
}

vue组件集成的关键代码

     /**
    * 获取组件的html
    */
    getElemtHtml() {

        let cmpAttr = this.getVueAttrStr(),
            onClickEvent = ''
        return [
            , '<el-steps ' + cmpAttr + ' ' + onClickEvent + this.doGetCmpIdTypeStr() + '>' + this.getItemsHtml() + '</el-steps>'
        ].join('')
    }
    getItemsHtml() {
        let ret = [];
        for (let i = 0; i < this.steps.length; i++) {
            const step = this.steps[i];
            let attrTitle = this.getAttrStr(step.title, 'title'),
                Description = this.getAttrStr(step.description, 'description'),
                AttrIcon = this.getAttrStr(step.icon, 'icon');
            let cmpAttr = AttrIcon + attrTitle
            ret.push('<el-step ' + cmpAttr + Description + '></el-step>')
        }
        return ret.join('')
    }

    /**
     * 设置默认值
     */
    doGetVueData() {
        let vueData = super.doGetVueData()
        return vueData
    }
    /**
     * 事件
     */
    doGetMethods() {
        let ret = super.doGetMethods();
        let that = this;
        return _.merge(ret, {
            next() {
                that.nextStep();
            }
        })
    }

组件效果图
